200GPH @ 20PSI Variable Speed Brushless Fuel Pump - 41404

• High Flow Carbureted In Line Fuel Pump, rated up to 2000HP, Street/Strip, Speed Adjustable DC Brushless fuel pump, External bypass
• Limited Lifetime Warranty
• Actual Colors May Vary From Image Shown

200 GPH @ 20 PSI, 30 PSI MAX - RATED UP TO 2000HP - Developed from our successful 41403 model, we take all the benefits of a high flow in-line pump and integrate a bypass valve directly into the outlet assembly of the pump.

Pump Features

• Compatible with gasoline, diesel, methanol, and ethanol
• Externally bypassed at 30 PSI
• High efficiency sling vane positive displacement pump
• Special housing shape for extremely quiet operation and steady pressure
• Carbon 9-vane construction with pressure balanced rotor for high reliability
• Backed by a limited lifetime warranty

Motor Features

• Lightweight super-efficient dc brushless motor reduces current draw
• Low mass rotor for high speed reaction to changes in speed and flow
• Powerful high flux density Neodymium rare earth magnets
• No motor brushes to wear out or corrode (low-Sulfur diesel, no problem)
• Wet motor design, no dynamic shaft seals that can wear out

Electronic Features

• Internal speed controller for variable flow operation
• 12 to 24 volt vehicle electrical system compatibility
• Accepts PWM input for speed control
• No expensive add-on voltage regulators or pump controllers required!
• Continuous duty–motor speed can be adjusted to meet fuel demand

Construction Features

• Compact, lightweight design, less than 3 lbs, overall length 6.9", diameter 2.63"
• Billet Aluminum Construction with anodize per MIL-A-8625, Type II
• High quality mounting brackets included
• Long-life, multi-fuel compatible Fluorosilicone static seals!
• Accepts standard or port style –10AN fittings

.

Technical Sheets

4140x Technical Data Sheet
