FUELAB 340LPH Series In-Tank Fuel Pump for GM Applications - 49469

• High Output In Tank Electric Fuel Pump 340LPH Center Offset (GM app)
• Limited Lifetime Warranty

E85 Compatible, Flows 340LPH. INLET IN LINE WITH OUTLET (GM APPLICATIONS)

Pump Features

• Flows 340LPH @ 3bar, 13.5v (90 GPH @ 45psi)
• Internal Check Valve
• Maximum Pressure – 5.9 Bar (85psi)
• Can be used in carbureted and EFI applications
• Each pump is individually tested for performance and includes flow and current draw report

Construction Features

• 80 mm body length for OE fitment, Inlet In-Line with Outlet (GM app)
• Inlet Size – 19mm
• Outlet Size – 9mm (5/16”) Hose Barb
• Designed for in-tank use only
• Sending Unit not included
• Comes with rubber sleeve, end cap, pre-filter, hose, clamps and wire leads

Technical Sheets

494xx Technical Data Sheet
